2270U OMNI UNIVERSAL IGNITOR PRIMARY VOLTAGE: 12VDC

Manufacturer: Allanson

- Input Voltage 12V, 2.5 Amps, 36VA - Grounding Mid Point Ground - Current 20mA - Secondary Voltage 17.5 kVpk, 12mA - Hv Terminal Large Spring Contact - Poles Double - Application Oil - Burner Manufacturer OMNI Universal Ignitor Features: - Eliminates need for other mounting plates helping to minimize inventory requirements - History of excellent operation under brownout conditions - Quick & easy to change - Energy efficient - Low operating temperature - Ships complete with required hardware - Meets American and European noise emission standards offering superior EMI and RFI protection - Storage Temperature: -40°C to 80°C - Operating Temperature: -30°C to 40°C - Operating Relative Humidity: 90% - Loading Air Gap: 1/16″ – 3/16″ - Dimensions 4.06″ x 4.92″ x 2.91″ (Does Not Include Base Plate) Unlike competitive units, Allanson’s OMNI Electronic Ignitors are truly universal and will mount onto any manufacturers existing electronic ignitor mounting plate – resulting in a perfect fit, every time. With up to three different models to choose from, installation on any application will be effortless. Each OMNI Ignitor comes complete with required hardware, providing even more convenience, making your service calls quick and easy. 2270U

SKU: ALLANSON:2270U

Product Availability: 3

$91.06

This product must be purchased in increments of 1

Qty:

i h

- Input Voltage 12V, 2.5 Amps, 36VA
- Grounding Mid Point Ground
- Current 20mA
- Secondary Voltage 17.5 kVpk, 12mA
- Hv Terminal Large Spring Contact
- Poles Double
- Application Oil
- Burner Manufacturer OMNI Universal Ignitor

Features:
- Eliminates need for other mounting plates helping to minimize inventory requirements
- History of excellent operation under brownout conditions
- Quick & easy to change
- Energy efficient
- Low operating temperature
- Ships complete with required hardware
- Meets American and European noise emission standards offering superior EMI and RFI protection
- Storage Temperature: -40°C to 80°C
- Operating Temperature: -30°C to 40°C
- Operating Relative Humidity: 90%
- Loading Air Gap: 1/16″ – 3/16″
- Dimensions 4.06″ x 4.92″ x 2.91″

(Does Not Include Base Plate)

Unlike competitive units, Allanson’s OMNI Electronic Ignitors are truly universal and will mount onto any manufacturers existing electronic ignitor mounting plate – resulting in a perfect fit, every time. With up to three different models to choose from, installation on any application will be effortless. Each OMNI Ignitor comes complete with required hardware, providing even more convenience, making your service calls quick and easy.

2270U

Products specifications
