DCA NSR 1-1/2 STROKE 405 LBF 0-10/2-10 VDC O

Manufacturer: Honeywell

- 24V - Torque 405 lb-in - Fail Safe Mode Non-Spring Return - Timing 175 Seconds - Actuator Type Floating / Proportional - Temp Range 14 to 122 F - 60/50Hz - Control Signal 2 to 10 Vdc - Stroke 1-1/2 (38) - 16VA FEATURES • Quick and easy installation. • No separate linkage or adjustments required. • High close-off ratings. • Force-limiting end switches. • Synchronous motor. • Maintenance-free, corrosion-resistant design. • Manual operator. • Conduit connector standard on ML6420, ML7420 • Conduit knockout standard on ML6421, ML7421. • Accurate valve positioning. • Low power consumption. • Direct/reverse acting with ML7420, ML7421. • Position feedback signal with ML7420, ML7421. The ML6420, ML7420, ML6421, and ML7421 Non-Spring Return Electric Linear Valve Actuators provide single-pole double-throw (spdt), Series 60 two-position and floating or modulating control to operate standard Honeywell valves in heating, ventilating, and air conditioning (HVAC) applications. The modulating actuators accept an analog output of 0 to 10 Vdc or 2 to 10 Vdc, and an internal selector plug can be used to reverse the direction of action. ML7421B1023

SKU: HONEYWELL:ML7421B1023

Product Availability: Out of stock

$575.61

This product must be purchased in increments of 1

Qty:

i h

- 24V
- Torque 405 lb-in
- Fail Safe Mode Non-Spring Return
- Timing 175 Seconds
- Actuator Type Floating / Proportional
- Temp Range 14 to 122 F
- 60/50Hz
- Control Signal 2 to 10 Vdc
- Stroke 1-1/2 (38)
- 16VA

FEATURES
• Quick and easy installation.
• No separate linkage or adjustments required.
• High close-off ratings.
• Force-limiting end switches.
• Synchronous motor.
• Maintenance-free, corrosion-resistant design.
• Manual operator.
• Conduit connector standard on ML6420, ML7420
• Conduit knockout standard on ML6421, ML7421.
• Accurate valve positioning.
• Low power consumption.
• Direct/reverse acting with ML7420, ML7421.
• Position feedback signal with ML7420, ML7421.

The ML6420, ML7420, ML6421, and ML7421 Non-Spring Return Electric Linear Valve Actuators provide single-pole double-throw (spdt), Series 60 two-position and floating or modulating control to operate standard Honeywell valves in heating, ventilating, and air conditioning (HVAC) applications.
The modulating actuators accept an analog output of 0 to 10 Vdc or 2 to 10 Vdc, and an internal selector plug can be used to reverse the direction of action.

ML7421B1023

Products specifications

Manufacturer	Honeywell
