⚡ Carlin 41000 120V Electronic Oil Burner Ignitor – Ignitor Only (No Base Plate) 🔧
The Carlin 41000 is a high-performance 120V electronic oil burner ignitor designed for smooth, reliable ignition in standard oil burner systems. Built with solid-state technology, it delivers consistent high-voltage output for long life, durability, and efficient performance.
This ignitor is constant-duty rated, ensuring safe extended operation, and its epoxy sealant protects against moisture while dissipating heat effectively. It is ideal for both traditional oil burner applications and select high-voltage experimental setups such as plasma systems.
Key Features ✅
-
✅ 19,000-volt output for smooth, reliable ignition
-
✅ Solid-state technology for long life, high performance, and durability
-
✅ Constant-duty rated – designed for extended operation without overheating
-
✅ Low current draw saves electricity
-
✅ Epoxy sealant provides water resistance and heat dissipation
-
✅ Consistent voltage output across a wide range of input voltages
-
✅ Versatile applications – some users successfully use in plasma setups
Technical Specifications 📝
| Specification | Value |
|---|
| Ignitor Model |
41000 |
| Power Input |
120 VAC, 60 Hz, 40 VA |
| Ignitor Output |
19 KV, 35 mA RMS |
| Secondary Grounding |
Midpoint |
| Operating Temperature |
+32°F to +140°F 🌡 |
| Storage Temperature |
-40°F to +185°F ❄️ |
Replaces / Cross Reference 🔄
-
Carlin: 41000
-
Clean Burn: 33189
-
Embassy: 60510015
Common Applications ⚡
Common Symptoms Solved ⚡
-
❌ Burner fails to ignite
-
❌ Ignitor sparks inconsistently
-
❌ Burner lockouts due to weak or intermittent ignition
-
❌ Premature ignitor failure from high usage
-
❌ Ignitor overheating during continuous operation
-
❌ Oil burner fails to start reliably after service or replacement
Shopping Tips 🛒
-
✅ Check Compatibility – Ensure your burner matches this ignitor; replaces Clean Burn 33189 and Embassy 60510015.
-
✅ Understand Your Setup – Sold without a base plate; verify your system has proper mounting or purchase a compatible plate.
-
✅ High-Voltage Requirement – Delivers 19,000 volts; confirm your application can safely handle this output.
-
✅ Constant-Duty Rated – Can operate continuously without overheating.
-
✅ Power Supply Check – Requires 120 VAC, 60 Hz, 40 VA input.
-
✅ Durability & Protection – Epoxy sealant provides water resistance and heat dissipation.
-
✅ Alternative Uses – Suitable for experimental high-voltage applications if compatible.
-
✅ Buy from Trusted Vendors – Ensures genuine parts and optimal performance.
Frequently Asked Questions (FAQ) ❓
Q: Does this ignitor come with a base plate?
✅ No, the Carlin 41000 is sold as ignitor only (no base plate).
Q: Is it compatible with other brands?
✅ Yes, it replaces Clean Burn 33189 and Embassy 60510015.
Q: Can this ignitor run continuously?
✅ ✅ Yes, it is constant-duty rated for long-term operation.
Q: What makes the 41000 more efficient?
✅ Low current draw saves electricity while delivering consistent high-voltage output.
Q: Can it be used in applications other than oil burners?
✅ Some customers have successfully used it in plasma applications due to its high voltage and continuous-duty capability.
Q: What temperature ranges can it operate in?
✅ Operating range: +32°F to +140°F, storage range: -40°F to +185°F.
