This oil burner setting gauge is designed to adjust the appropriate distance between the nozzle and the combustion head and the angle of the electrode without removing the oil burner from the heating equipment.
Compatible Models: The oil burner gauge is compatible for beckett AF, AFG, SR, SF burners with "F" head, AF lI burner with "FB" head, and any nozzle recommended by furnace or boiler manufacturer. Please confirm whether the kit is suitable for your burner
This setting gauge for nozzle & electrode is placed on the nozzle with the opening facing up. The bump at the top of the gauge is used to adjust the correct angle of the electrode, and the protrusion at the front is used to position the distance between the nozzle and the retention head.
Benefit
Adjusting to the correct nozzle distance and electrode angle through the gauge kit allows you to reduce fuel consumption and achieve better combustion.
Beckett Z2000U Nozzle Assembly And Electrode Setting Gauge
The Beckett Z gauge is designed for use on Beckett AF, AFG, SR and SF oil burners that use the “F” style retention head, and AFII burners with ”FB” style retention heads.
The Beckett Z gauge enables the technician to set the nozzle to the proper distance from the combustion head without removal of the oil burner from the heating appliance. It also allows the technician to conveniently adjust the electrodes to Beckett specifications.
