PF20322U Beckett 120V Single-Stage CleanCut Oil Pump – 4 GPH
The Beckett PF20322U CleanCut Oil Pump is a high-performance, single-stage pump designed for modern oil heating systems. With UL Listing for fuels up to 100% biodiesel (B100), it combines reliable operation, cleaner combustion, and motor efficiency. Ideal for residential and commercial applications, this pump delivers up to 4 GPH at 100 PSI while maintaining smoother light-offs and reduced motor load.
✅ Key Features
-
Single-Stage Pump – provides consistent fuel delivery up to 4 GPH
-
Max Pressure: 200 PSI
-
Voltage: 120V AC, 50/60Hz
-
Contains Solenoid Valve: Suntec 3713824, 9 Watts, IP54 protection
-
Cleaner Operation: solenoid valve cuts oil flow instantly to prevent soot formation during shutdown
-
Pre-Purge Compatible: works with pre-purge controls for smoother start-up and light-off
-
More Reliable: fewer moving parts than conventional pumps reduces maintenance needs
-
Reduced Motor Load: bypass design minimizes stress on the motor during start-up
-
Leak-Through Protection: same piston valve design as traditional pumps prevents leak-through
-
Higher Capacity: delivers up to 4 GPH at 100 PSI; 2 GPH at 150–200 PSI
-
Biodiesel Ready: UL Listed for fuels up to 100% B100
📊 Technical Specifications
| Specification | Details |
|---|
| Manufacturer |
Beckett |
| Part Number |
PF20322U |
| Application |
Single-Stage Oil Pump |
| Flow Rate |
4 GPH @ 100–150 PSI; 2 GPH @ 150–200 PSI |
| Max Pressure |
200 PSI |
| Voltage |
120V AC, 50/60Hz |
| Solenoid |
Suntec 3713824, 9 W, IP54 |
| Fuel Compatibility |
Oil, B100 biodiesel |
| Previous Beckett Part No. |
PF10322U |
| Replaces Suntec / Beckett |
A2EA-6520, A2EA6520, A2EA-6528, A2EA6528 |
| Functional Replacement |
Danfoss 071N1180 (without delay timer) |
| UL Listed |
Yes – fuels up to B100 |
⚡ Common Problems Solved
❌ Oil burners failing to start smoothly
❌ Soot formation on shutdown due to coasting stops
❌ Pump overloading motor during start-up
❌ Leak-through issues in gravity feed systems
❌ Replacing older or incompatible single-stage pumps
🛒 Shopping Tips
✅ Confirm Flow Requirements – 4 GPH at 100 PSI for standard applications; 2 GPH at 150–200 PSI.
✅ Check Voltage & Frequency – 120V AC, 50/60 Hz.
✅ Verify Compatibility – Replaces Beckett A2EA6520/A2EA6528, Danfoss 071N1180; functional replacement only.
✅ Consider Additional Parts – Delay timer not included (use Beckett 21887U); power cord sold separately (21807U).
✅ Motor Efficiency – Reduced load on motor during start-up ensures longer pump life.
❓ Frequently Asked Questions (FAQ)
Q: What is the maximum flow rate of the PF20322U?
✅ 4 GPH at 100–150 PSI; 2 GPH at 150–200 PSI.
Q: Can it handle biodiesel?
✅ Yes, UL Listed for fuels up to 100% B100.
Q: Does this pump include a delay timer or power cord?
✅ No, these are sold separately (delay timer: 21887U, power cord: 21807U).
Q: Which pumps does this replace?
✅ Beckett A2EA6520, A2EA-6520, A2EA-6528, A2EA6528; functional replacement for Danfoss 071N1180.
Q: What makes the CleanCut design better than conventional pumps?
✅ Instant shut-off prevents soot, pre-purge compatibility ensures smooth start-up, fewer moving parts reduce maintenance, and bypass design lowers motor stress.
