Clean Operation
Patented air guide and scroll insert deliver high static pressure to provide clean combustion in modern appliances, even in tough situations.
Quiet Operation
The standard sound cover and high-quality components provide quiet operation.
Adapts to Outside Air
High static pressure and the air intake kit are ideal for direct venting.
Easy to Service
The NX uses standard components, combines air and head settings into one adjustment and allows the zero position to be set without removing the burner
|
Capacities
- 0.40 to 1.75 gph
- 56,000 to 280,000 BTU/hr input
Fuels
- No. 1 or No. 2 heating oil (ASTM D396) only
Dimensions (standard)
- Height: 12-1/2'
- Width: 15'
- Depth: 9-1/4'
Electrical Characteristics
- Motor: 3450 rpm, NEMA M-flange
- Power Supply: 120 V./60Hz./1 phase
- Ignition: Continuous duty solid state igniter
- Operating Load: 2.0 amps (maximum)
Fuel Unit
- Single stage
|
The NX is now available on:
- Biasi
- Boyertown Furnace
- Buderus
- Burnham
- Crown Boiler Company
- Peerless Heater
- Slant Fin
- Thermo Dynamics
- Triangle Tube
- Viessmann
- Weil-McLain
|
