Beckett 52082U GeniSy Control Contractor Tool Description: The Contractor Tool is designed as a portable diagnostic tool to help technicians program and troubleshoot Beckett oil primary controls. The screen shows current burner status, control timings, and burner cycle history.
The programming mode allows a technician to customize both the pre-time and post-time settings.
Specifications Voltage: 5 VDC Current: 25 mA maximum display current Storage Ambient Temperature: -22°F to +150°F (-30°C to +65°C) Operating Ambient Temperature: 0°F to +150°F (-18°C to +65°C) Moisture: 5-85% RH, non-condensing and non-crystallizing
Features & Benefits
- 32 character backlit alphanumeric display Sealed pushbutton keypad
- Low voltage operation
- Continuous real-time cycle monitoring
- Continuous cad cell resistance reading
- Continuous AC line voltage readout
- Real-time error notification
- Customizable pre-time (valve-on delay) & post-time (Motor off delay)
- 15 cycle history monitoring
- 5-year warranty
- Customizable lockout service message Replaces Beckett 52067U
